Challenger® SB Series Small Square Balers
The Challenger SB Series "Center-Line Balers" give you the options
you want and the features you need to produce high quality hay. The center-line
design allows crop to move in a straight line from the time it leaves the pickup
until it drops out the back as a finished bale. By using this advanced bale-forming
concept, we have eliminated many high maintenance cross-conveying mechanisms still
used in other baler designs.
If quality hay, unmatched maneuverability and high capacity are required, the Challenger
SB Series center-line balers will fill the need.
For complete specs download a pdf brochure by
clicking here.
| Model | SB34 | SB36 | SB44 |
| Overall Width | 101 in. | 101 in. | 104 in. |
| Bale Chamber | 14 x 18 in. | 14 x 18 in. | 16 x 18 in. |
| Bale Length | 12 to 52 in. | 12 to 52 in. | 12 to 52 in. |
| Density Control | Spring Loaded | Spring Loaded | Hydraulic |
| Tying Mechanism | Twine 4 Balls | Twine 4 Balls | Twine 6 Balls |
| PTO | 540 rpm | 540 rpm | 540 rpm |
| Pickup Width | 75.9 in. | 75.9 in. | 77.5 in. |
| Req. Horsepower | 35 hp | 35 hp | 50 hp |
|
|
Challenger® LB Series Large Square Balers
The Challenger LB Series big balers are well suited to be used by
custom operators, dairy farmers and hay or straw operations. The LB44 is built to
bale hay straw, and package it in the largest bale in the industry. The LB34 and
LB33 are designed to bale hay, silage and straw. The Challenger balers make solid,
high density bales that stack and ship with ease. The big bales reduce the number
of bales handled and stored, cutting manpower requirements to a minimum.
For complete specs download a pdf brochure by
clicking here.
| Model | LB33 | LB34 | LB44 |
| Overall Width
| 100 in.
| 117 in.
| 125.5 in.
|
| Bale Size w x h
| 31.5 x 34.4 in.
| 47.3 x 34.4 in.
| 46.5 x 50 in.
|
| Bale Length
| Up to 98 in.
| Up to 98 in.
| Up to 108 in.
|
| Density Control
| Microprocessor Based
| Microprocessor Based
| Microprocessor Based
|
| Tying Mechanism
| Twine 20 Balls
| Twine 30 Balls
| Twine 24 Balls
|
| PTO
| 1000 rpm
| 1000 rpm
| 1000 rpm
|
| Pickup Width
| 77.5 in.
| 87.9 in.
| 83.6 in.
|
| Req. Horsepower
| 90 hp
| 120 hp
| 135 hp
|
|
|
Challenger® RB Series Round Balers
The RB34 round baler is the smallest baler in the Challenger variable
chamber round baler line. The RB34 baler is sized primarily for operators with lower
horsepower tractors. The RB34 is ideal for the smaller farmer who wants to move
from small square bales to easier to handle round bales. It is also ideal for the
small farmer who wants to move away from hiring a custom round bale operator and
have control over the timing of his baling. The RB34 is also a good fit for the
smaller farmer that is tired of the frequent breakdowns with used balers and wants
to move into a new, more dependable baler.
The Model RB44 round baler is the second smallest baler in the Challenger® variable
chamber round baler line. The RB44 baler is targeted toward farmers needing round
balers, but not a large bale package.
The Challenger® RB46 and RB56 are both "Fully Automatic" Round Balers. The RB46
is a 4' wide by up to 6' diameter Variable Chamber Round Baler, while the RB56 is
a 5' wide by up to 6' diameter Variable Chamber Round Baler. By "Fully Automatic"
We mean that the baler takes over the tedious manual inputs previously required
in the Round Bale making process (i.e.: wrapping, stopping the PTO, opening the
tailgate, ejecting the bale, closing the tailgate and restarting the forming belts).
An Operator/Baler can be much more productive when manual inputs are not required.
For complete specs on the RB34 download a pdf brochure by
clicking here.
For complete specs on the RB44 download a pdf brochure by
clicking here.
For complete specs on the RB46 and RB56 download a pdf brochure by
clicking here.
| Model | RB34 | RB44 | RB46 | RB56 |
| Overall Width | 81 in. | 86 in. | 111 in. | 126 in. |
| Bale Size Dia. | 30 in. to 52 in. | 30 in. to 52 in. | 30 in. to 72 in. | 30 in. to 72 in. |
| Bale Width | 39.4 in. | 47 in. | 46.5 in. | 61.5 in. |
| Bale Volume | 51.7 cu. ft. | 57 cu. ft. | 119 cu. ft. | 145 cu. ft. |
| Twine Storage | Twine 2 Balls | Twine 4 Balls | Twine 8 Balls | Twine 8 Balls |
| PTO | 540 rpm | 540 rpm | 540 rpm or 1000 rpm
| 540 rpm or 1000 rpm
|
| Pickup Width | 39 in. | 49 in. | 66 in. | 83.6 in. |
| Req. Horsepower | 30 hp | 45 hp | 65 hp | 70 hp |
|
|
|
|
